Full-Spectrum Denial Anti-Drone System – Precision Spoofing, Multi-Band Jamming, Omnidirectional Coverage

Name: Full-Spectrum Denial Anti-Drone System – Precision Spoofing, Multi-Band Jamming, Omnidirectional Coverage
Brand: Chongqing Leikan Technology Co., Ltd
SKU: Los requisitos de seguridad de los equipos de ensayo deberán cumplirse en todos los casos.
Availability: InStock

Detalles del producto:

Nombre de la marca:	LeiKan
Número de modelo:	Los requisitos de seguridad de los equipos de ensayo deberán cumplirse en todos los casos.

Información Detallada

Nombre de la marca:

LeiKan

Número de modelo:

Los requisitos de seguridad de los equipos de ensayo deberán cumplirse en todos los casos.

Sin emisión de onda electromagnética:

Compatible con áreas sensibles electromagnéticas

Supresión multifrecuencia:

el cambio de banda con un solo clic engaña con precisión a los vehículos aéreos no tripulados (UAV)

Suplantación de esfera completa:

Suplantación: cobertura horizontal de 360° y vertical de 0–90° elimina la rotación mecánica y suprim

Respuesta inmediata:

Bloqueo y simulación dentro de ≤10 s, activando instantáneamente el aterrizaje forzoso, la expulsión

Resaltar:

High Light

Resaltar:

full-spectrum anti-drone system

multi-band drone jamming system

omnidirectional drone spoofing system

Información Comercial

Cantidad de orden mínima:

Condiciones de pago:

LC, D/A, D/P, T/T, Western Union, MoneyGram

Descripción del Producto

Ⅰ. Product Overview

The is a stationary navigation-spoofing system designed for counter-UAV operations. It synthesizes and radiates GNSS signals that are bit-for-bit identical to authentic on-orbit satellite constellations. By position-spoofing, velocity-spoofing and time-spoofing, the system manipulates any UAV that relies on GPS/GLONASS (and optionally Galileo or BeiDou) for navigation. Typical outcomes include forced landing, expulsion, guided diversion to a predetermined location, or prevention of take-off within a protected zone.

The device has low radiation power and has no impact on the surrounding electromagnetic environment, which can prevent secondary damage caused by high-power electromagnetic suppression, such as the falling of a drone carrying a bomb. Widely used in refineries, oil depots, gas stations and other places.

It can be connected to various types of unmanned aerial vehicle detection and countermeasures equipment, such as intelligent perception detection, navigation deception control, wireless voltage based interference interception, etc. Having customizable unmanned and automated disposal strategies to meet the needs of various fields for low altitude security of drones

Ⅱ. Key Features

Integrated GNSS receiver for real-time synchronization with on-orbit satellites.
Adjustable RF output; external amplifier modules can be fitted to extend engagement range.
Capable of forced landing, expulsion, directed diversion and no-fly enforcement.
Emits spoofing patterns that drive the UAV into circular, straight, constant-speed, variable-speed or curved trajectories.

Ⅲ.Technical Parameters

Parameter	Value
Operating Bands	GPS-L1: 1575.42 MHz ± 1.023 MHz
	GLONASS-L1:1602 MHz + N × 0.5625 MHz ± 0.511 MHz (N = −7 … +6)
	Galileo-E1: 1575.42 MHz ± 12.276
	MHzBeiDou-B1:1561.098 MHz ± 2.046
	MHz(customizable)
Operating Mode	Real-time generation of GPS-L1 and GLONASS-L1 spoofing signals; optional generation of Galileo-E1 and BeiDou-B1 spoofing signals
Spoofing Range	0.5–1 km at 10 mW (EIRP)Greater range achievable by increasing transmit power
Spoofing Response Time	≤ 10 s (within effective range)
Effective Spoofing Angle	Horizontal: 360°Vertical: 0–90°
Simultaneous Counter-UAV Capacity	Unlimited
RF Transmit Power	10 mW (EIRP) base unit
Continuous Operation	≥ 24 h
Dimensions	420 mm × 370 mm
Weight	≤ 10 kg

IV.Usage scenarios

No fly zones: important sensitive locations such as airports, prisons, and nuclear industry facilities.

Important infrastructure: such as petroleum and petrochemical, power, water conservancy engineering, water source areas, scenic spots, etc

Sensitive areas: important security locations, accompanying political figures for protection, performance rehearsals, archaeological sites, etc.

V.software platform
